ECOdrive 32P-D1Z0D
EC32P-D1Z0D1 : ECOdrive DC, 32W, DALI-2, 1 control channel, constant current, 1x 40V LED output, open frame, compatible with Stucchi MULTISYSTEM track adapter
Any further information, please contact us
ECOdrive 32/P – 32W 1% DALI for 48V track
LED technology enables further miniaturization of track lighting. To meet the ever-tighter form factor constraints, these tracks rely on small LED drivers that are powered by a remote 48V DC power supply.
eldoLED developed a range of products that are mechanically designed to have a seamless integration into the track adapters of the Stucchi MULTISYSTEM and MULTISYSTEM EVO track systems. This LED driver delivers on the Quality of Light functionality that is required for specification-grade luminaires. eldoLED delivers on the promise of LED lighting in this application, by deep dimming to 1%, meeting IEEE P1789 recommendation on flicker, and controls interoperable by being DALI-2 certified.
Benefits
- Solving the dimming performance issues in track lighting installations by dimming smoothly all the way to 1%
- Compatible with a wide variety of COB and LED configurations
- Mechanically designed for the Stucchi MULTISYSTEM / MULTISYSTEM EVO track system adapters
- Optimized design of no need for wires for power and control
- Fast pre-assemble capabilities – programming based on project/product requirements
Specification
- Input voltage of 48Vdc
- Wide output voltage range from 9 to 40V
- Programmable output current from 150 to 1050mA
- Open PCB product
- Designed for the Stucchi MULTISYSTEM / MULTISYSTEM EVO track luminaire adapter
- Blades for direct connection into adapter
- Dimensions: 136.4 (L) x 14.5 (W) x 12.0 (H) mm
Certifications
- Europe: CE & ENEC-05
- North America: UL Recognized
- Controls: DALI-2 Device Type 6
Input characteristics
Nominal input voltage range 48VDC ± 2VDC
Efficiency at full load 91%
Maximum standby power < 5mW
Output characteristics
Maximum LED output power 32W
Number of LED outputs 1
Programmable LED output current range 150 – 1050mA
LED output current resolution Programmable in 1mA increments within specified current range
LED output type Constant current
LED output current tolerance +/- 5% at programmed LED output current
LED output voltage range 9 – 40V
Control characteristics
Control channels 1
Control protocol DALI-2 Device Type 6
Dimming range 100% – 1%
Dimming curve options Logarithmic (default) ; Linear
Dimming method : hybrid hydradrive
