SOLOdrive 266/U

SL0266U : SOLOdrive AC, 20W, 0-10V + aux, 1 control channel, constant current, single output, long metal


Any further information, please contact us

SOLOdrive 266/U delivers 20W and is 0-10V compatible. As all SOLOdrives, the 266/U smoothly dims all the way down to zero.

Features

  • Hybrid HydraDrive: provides the smoothest flicker-free high-performance dimming to zero for every fixture
  • Auxiliary power output
  • LEDcode technology: configurable design to work with most constant current LED modules and arrays, while providing a connection point to integrated peripheral controls
  • NTC interface for robust thermal management

Benefits

  • Increase performance and capability of any LED fixture
  • Reduce inventory and decrease lead times with configurable drivers
  • Short lead times, designed to meet the most aggressive timelines
  • Trusted brand with proven track record of performance and reliability

Certifications

  • CE
  • EN 61347-1/-2-13, EN 62384, EN 55015, EN 55022, EN 61000-3-2, EN 61547
  • UL: Recognized Component (E333135), according to UL131 0 and UL8750. US/Canada: Isolated, Class 2 output.
  • ENEC by DEKRA
  • EL
  • RCM

Input characteristics
Nominal input voltage range AC 120 – 250V (ENEC), 120 – 277V (UL)
Absolute input voltage range AC 108 – 305V
Nominal input voltage range DC 120 – 250V
Maximum input current 0.3A @ 120V / 60Hz ; 0.15A @ 230V / 50Hz ; 0.12A @ 277V / 60Hz
Input frequency range 50 – 60Hz
Efficiency at full load 83%
Power factor at full load 0.95
THD at full load < 20%
Maximum inrush current < 200mA²s @ 120V / 60Hz ; < 200mA²s @ 230V / 50Hz ; < 200mA²s @ 277V / 60Hz
Surge protection 2kV differential mode (DM) ; 2kV common mode (CM)
Maximum standby power <0.5W ; If no load connected to the AUX output

Output characteristics
Maximum LED output power 22W
Number of LED outputs 1 (UL Class 2)
Programmable LED output current range 150 – 1400mA
LED output type Programmable in 1mA increments within specified current range
LED output current tolerance +/- 5% at programmed LED output current
LED output voltage range 2 – 55V
Auxiliary output 15.5-25V DC, 18mA max

Control characteristics
Control channels 1
Control protocol 0-10V ; LEDcode
Dimming range 100% – 0.1%
Dimming curve options Logarithmic (default) ; Linear ; Soft-Linear ; Square
Dimming method Hybrid HydraDrive
0-10V current draw 0.48mA
Time delay to standby < 25s

Dimensions 28 × 3 × 2,1 cm
